NL17SZ17P5T5G The NL17SZ17P5T5G is a single non-inverting buffer with a Schmitt trigger input from ON Semiconductor. It operates from 1.65V to 5.5V and is available in a SOT-953 package.
Mfr Part #:

NL17SZ17P5T5G

Available from 1 distributors
Mfr Name: On Semiconductor
On Semiconductor
The NL17SZ17P5T5G is a single non-inverting buffer with a Schmitt trigger input from ON Semiconductor. It operates from 1.65V to 5.5V and is available in a SOT-953 package.
✓ Total Stock: 192,000 pcs
$ Price Range: $1.20

NL17SZ17P5T5G Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Flip Electronics ✓
Non-Authorised Inventory information
192,000 pcs
On Request
192000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

NL17SZ17P5T5G Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
Halogen Free
Input Type
Junction Temperature
Logic Type
Mounting Type
Number of Bits per Element
Number of Elements
Operating Temperature
Output Type
Propagation Delay
Supplier Device Package
Voltage
View Similar Products (0)

NL17SZ17P5T5G Description

Short technical summary and product information.

The NL17SZ17P5T5G is a single, non-inverting buffer featuring a Schmitt trigger input, manufactured by ON Semiconductor. This integrated circuit is designed for operation across a wide voltage range, from 1.65 V to 5.5 V.



Key electrical characteristics include a typical propagation delay of 3.7 ns at 5 V, and input/output overvoltage tolerance up to 5.5 V. The device supports partial power-down protection via its IOFF feature. It can source and sink up to 24 mA at 3.0 V.



This buffer is housed in a compact SOT-953 package, making it suitable for space-constrained applications. The operating temperature range is -55°C to 125°C (TA). The device is Pb-Free and Halogen Free, complying with RoHS standards.



Its Schmitt trigger input provides hysteresis, which helps to improve noise immunity and signal integrity in digital systems. This makes the NL17SZ17P5T5G a reliable choice for various logic interfacing and signal conditioning tasks.

NL17SZ17P5T5G Quick Information

Product Type: Buffer
Canonical Name: NL17SZ17 Single Non-Inverting Buffer with Schmitt Trigger
Subcategory: Non-Inverting Buffer with Schmitt Trigger

NL17SZ17P5T5G Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

NL17SZ17P5T5G Estimated Pricing

Qty Low High
1+ $1.20 $1.20

Estimated market price range - modelled values for guidance only, not live distributor offers.

NL17SZ17P5T5G Features

  • Single non-inverting buffer with Schmitt trigger.
  • Wide operating voltage from 1.65 V to 5.5 V.
  • Input/output overvoltage tolerant up to 5.5 V.
  • Compact SOT-953 surface mount package.
  • Pb-Free and Halogen Free compliance.

NL17SZ17P5T5G Applications

  • Digital signal buffering and conditioning.
  • Logic level translation applications.
  • Improving noise immunity in digital circuits.
  • Used in space-constrained designs.

NL17SZ17P5T5G FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating voltage range of the NL17SZ17P5T5G?

The NL17SZ17P5T5G operates from 1.65V to 5.5V.

What is the propagation delay of the NL17SZ17P5T5G?

The typical propagation delay is 3.7 ns at VCC = 5V.

What is the operating temperature range of the NL17SZ17P5T5G?

The operating temperature range is -55°C to 125°C.

What package is the NL17SZ17P5T5G available in?

The NL17SZ17P5T5G is available in a SOT-953 surface-mount package.

Is the NL17SZ17P5T5G lead-free and halogen-free?

Yes, the NL17SZ17P5T5G is lead-free and halogen-free as verified by the manufacturer's datasheet.

Does the NL17SZ17P5T5G have Schmitt trigger inputs?

Yes, the NL17SZ17P5T5G has Schmitt trigger inputs.

What is the output current capability of the NL17SZ17P5T5G?

The output can source or sink 24 mA at VCC = 3.0V.
