| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Overload Protection | |
| Package Quantity | |
| Power (Watts) | |
| Power Rating | |
| Rated Current | |
| Type | |
| Voltage | |
| Weight | |
| Width |
The Mean Well USA NES-75-48 is a versatile AC/DC power supply designed for various applications. It operates with a universal AC input range of 85V to 264V and provides a stable 48V DC output at a rated current of 1.6A, totaling 77W of power. This enclosed unit is designed for chassis mounting, offering convenience in system integration.
Key electrical specifications include a high efficiency of 87%, line and load regulation of ±0.5%, and overload protection ranging from 105% to 135% of the rated output power. It also features over-voltage protection and a withstand voltage of 3kVAC.
The operating temperature range is -20°C to 60°C with derating, and cooling is achieved through free air convection. The dimensions are 159mm in length, 97mm in width, and 38mm in height. Safety standards include UL60950-1 and CB(IEC60950-1) approval.
This power supply is suitable for ITE (Commercial) applications and comes with RoHS3 compliance and an MSL 1 rating.
The output voltage is 48V.
The rated current is 1.6A.
The power rating is 76.8W.
The operating temperature range is -20°C to 60°C with derating.
Cooling is achieved by free air convection.
The dimensions are 159mm x 97mm x 38mm.
It meets UL60950-1 and CB(IEC60950-1) safety standards.
