| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Overload Protection | |
| Power (Watts) | |
| SVHC Present | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Voltage Range |
The Mean Well USA NES-75-15 is a 75W enclosed AC/DC power supply designed for industrial applications. It provides a stable 15V output voltage with a rated current of 5A.
Key electrical specifications include a universal input voltage range of 85-264 VAC and a frequency range of 47-63 Hz. The unit boasts a high efficiency of 83% and features adjustable output, universal input, and overload protection.
Designed for reliable operation, the NES-75-15 operates within a temperature range of -20°C to 60°C and meets various safety standards including CB, CCC, and cURus. Its dimensions are 159.0mm x 97.0mm x 38.0mm, making it suitable for chassis mounting.
Compliance includes EN55022 (CISPR22) Class B for EMI, and it adheres to harmonic current standards EN61000-3-2,-3. EMS immunity is also covered under EN61000-4-2 through EN61000-6-1.
The output voltage is 15V.
The rated current is 5A.
The power rating is 75W.
The typical efficiency is 83%.
The operating temperature range is -20°C to 60°C.
It complies with CB, CCC, and cURus safety standards.
The dimensions are 159.0mm x 97.0mm x 38.0mm.
