NE556N The STMicroelectronics NE556N is a dual precision timer IC operating at 500kHz. It supports a wide supply voltage range and is housed in a 14-DIP package.
Mfr Part #:

NE556N

Available from 3 distributors
Mfr Name: ST
ST
The STMicroelectronics NE556N is a dual precision timer IC operating at 500kHz. It supports a wide supply voltage range and is housed in a 14-DIP package.
✓ Total Stock: 60,415 pcs
$ Price Range: $3.00

NE556N Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Romaks Technologies ✓
Non-Authorised Inventory information
60,267 pcs
On Request
60267 pcs On Request 1 On Request On Request On Request On Request On Request
Smaxon Electronics ✓
Non-Authorised Inventory information
138 pcs
On Request
138 pcs On Request 1 On Request On Request 97+ On Request On Request
Chanetech ✓
Non-Authorised Inventory information
10 pcs
On Request
10 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

NE556N Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Frequency
Industrial Grade
Lead Spacing
Lead Style
Mounting Type
Operating Temperature
Output Current
SVHC Present
Tape & Reel
View Similar Products (0)

NE556N Description

Short technical summary and product information.

The NE556N from STMicroelectronics is a dual precision timer integrated circuit designed for astable or monostable operation. It provides two independent timing circuits per package, capable of generating precise time delays from microseconds to hours.



Key electrical characteristics include a maximum frequency of 500kHz, a wide operating supply voltage range of 4.5V to 16V, and a supply current of 20mA. The output can sink or source up to 150mA, and it is TTL-compatible. The device operates within a temperature range of 0°C to 70°C.



This timer IC is suitable for a variety of applications such as pulse shaping, missing pulse detection, tone-burst generation, pulse-width and pulse-position modulation, sequential timing, and general application timing.



The NE556N is available in a 14-DIP package, designed for through-hole mounting.

NE556N Quick Information

Product Type: Dual Precision Timer
Canonical Name: NE556N Dual Precision Timer
Subcategory: Programmable Timers

NE556N Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1
REACH Status: REACH Unaffected

NE556N Estimated Pricing

Qty Low High
1+ $3.00 $3.00

Estimated market price range - modelled values for guidance only, not live distributor offers.

NE556N Features

  • Dual precision timing circuits per package.
  • Astable or monostable operation supported.
  • TTL-compatible output sinks/sources 150mA.
  • Operates from 4.5V to 16V supply.
  • Available in a 14-DIP through-hole package.

NE556N Applications

  • Used for pulse shaping circuits.
  • Suitable for missing-pulse detectors.
  • Enables tone-burst generators.
  • Applicable for pulse-width modulators.
  • Supports sequential timer applications.

NE556N FAQs

5 frequently asked questions generated from this part’s specifications.
What is the operating voltage range for the NE556N?

The NE556N operates from 4.5V to 16V.

What is the maximum frequency of the NE556N?

The NE556N has a maximum frequency of 500kHz.

What is the operating temperature range for the NE556N?

The NE556N operates from 0°C to 70°C.

What is the RoHS status of the NE556N?

The NE556N is RoHS3 Compliant.

What is the Moisture Sensitivity Level (MSL) for the NE556N?

The MSL for the NE556N is 1.
