NCP51530BMNTWG The ON Semiconductor NCP51530BMNTWG is a high-performance 700V high and low side gate driver. It offers 3.5A source and 3A sink current capabilities.
Mfr Part #:

NCP51530BMNTWG

Available from 3 distributors
Mfr Name: On Semiconductor
On Semiconductor
The ON Semiconductor NCP51530BMNTWG is a high-performance 700V high and low side gate driver. It offers 3.5A source and 3A sink current capabilities.
✓ Total Stock: 138,521 pcs
$ Price Range: $0.75

NCP51530BMNTWG Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Flip Electronics ✓
Non-Authorised Inventory information
135,521 pcs
On Request
135521 pcs On Request 1 On Request On Request On Request On Request On Request
Xingangxin ✓
Non-Authorised Inventory information
2,000 pcs
On Request
2000 pcs On Request 1 On Request On Request On Request On Request On Request
Braun Electronic Components ✓
Non-Authorised Inventory information
1,000 pcs
On Request
1000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

NCP51530BMNTWG Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Current
Fault Protection
Features
Interface
Load Type
Mounting Type
Operating Temperature
Output Configuration
Supplier Device Package
Technology
Voltage
Voltage Supply
View Similar Products (0)

NCP51530BMNTWG Description

Short technical summary and product information.

The ON Semiconductor NCP51530BMNTWG is a high-performance gate driver designed for AC-DC power supplies and inverters. It operates up to 700V and provides 3.5A source and 3A sink current drive capability.



This device features a typical propagation delay of 25 ns for the NCP51530B version, along with low quiescent and operating currents. It supports 3.3V and 5V input logic and offers high dv/dt immunity up to 50 V/ns. The NCP51530BMNTWG is pin-to-pin compatible with industry-standard half-bridge ICs.



Designed for highly efficient power supplies operating at high frequencies, applications include high-density SMPS for servers, telecom, and industrial sectors, as well as half/full-bridge and LLC converters, active clamp flyback/forward converters, solar inverters, and motor controls.



The NCP51530BMNTWG is available in a 10-DFN exposed pad package, suitable for surface mounting.

NCP51530BMNTWG Quick Information

Product Type: Gate Driver
Canonical Name: NCP51530BMNTWG High and Low Side Gate Driver
Subcategory: Full Half-Bridge Drivers

NCP51530BMNTWG Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

NCP51530BMNTWG Estimated Pricing

Qty Low High
1+ $0.75 $0.75

Estimated market price range - modelled values for guidance only, not live distributor offers.

NCP51530BMNTWG Features

  • 700V high voltage range capability.
  • 3.5A source and 3A sink currents.
  • 25 ns typical propagation delay.
  • 15 ns maximum rise and fall time.
  • 10-DFN exposed pad package.

NCP51530BMNTWG Applications

  • Used in AC-DC power supplies.
  • Suitable for inverter applications.
  • Ideal for high-density SMPS.
  • Applicable to LLC converters.
  • Used in solar inverters.

NCP51530BMNTWG FAQs

7 frequently asked questions generated from this part’s specifications.
What is the maximum voltage rating for the NCP51530BMNTWG?

The maximum voltage rating is 700 V.

What is the typical propagation delay of the NCP51530BMNTWG?

The typical propagation delay is 25 ns.

What are the source and sink current capabilities?

It offers 3.5 A source current and 3 A sink current.

What is the operating temperature range?

The operating temperature range is -40°C to 125°C (TJ).

What package type is the NCP51530BMNTWG supplied in?

It is supplied in a 10-VDFN exposed pad package.

What mounting type is recommended for this gate driver?

Surface mount is the recommended mounting type.

What logic levels are compatible with this device?

It is compatible with 3.3 V and 5 V input logic.
