| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
195 pcs
|
195 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Card Type | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Material | |
| Current Rating | |
| Features | |
| Flammability Rating | |
| Height Above Board | |
| Insertion, Removal Method | |
| Insulation Material | |
| Insulation Resistance (Minimum @ After Environmental Conditioning @ 500 VDC) | |
| Insulation Resistance (Minimum @ Initial @ 500 VDC) | |
| Lead Spacing | |
| Mounting Feature | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Operating Temperature Range | |
| Pitch | |
| Solder Reflow Temperature | |
| Termination Style | |
| Withstanding Voltage |
The 3M N7E50-C516PK-30 is a CompactFlash Type I card connector from the 7E50 series. It features 50 positions in a single row with 0.635 mm pitch. The connector is surface mounted with a right angle orientation and has a low profile height of 4.00 mm above the board. It includes board guide and card guide features for easy insertion and removal. The contacts are made of copper alloy with gold flash plating over palladium nickel. The insulator is liquid crystal polymer (LCP) with UL 94V-0 flammability rating. Electrical specifications include a current rating of 0.5 A, insulation resistance of >1×10^9 Ω at 500 VDC, and withstanding voltage of 500 VRMS at sea level. Operating temperature range is -55°C to +85°C, with a maximum solder reflow temperature of 260°C. The connector is RoHS3 compliant and has MSL 1 unlimited. It is designed for CompactFlash Type I cards and is suitable for industrial and consumer applications requiring reliable memory card connections.
| Qty | Low | High |
|---|---|---|
| 1+ | $15.34 | $15.34 |
| 10+ | $13.60 | $13.60 |
| 20+ | $13.04 | $13.04 |
| 50+ | $9.99 | $9.99 |
| 100+ | $9.83 | $9.83 |
| 200+ | $9.70 | $9.70 |
| 500+ | $9.65 | $9.65 |
| 1,000+ | $9.59 | $9.59 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
50 positions.
0.635 mm.
0.5 A.
Surface Mount, Right Angle.
-55°C to +85°C.
>1×10^9 Ω at 500 VDC (initial), >1×10^8 Ω after environmental conditioning.
Yes, RoHS3 compliant (unverified).
