| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
22 pcs
|
22 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination |
The 3M N2530-5002-RB is a 30-position, 2-row shrouded header (male pin) connector designed for board-to-board or cable applications. It features a 2.54mm (0.100") pitch with right-angle, through-hole termination for solder mounting.
All positions are loaded with square, tin-plated copper alloy contacts. The insulator is black glass-filled PCT (polyester) rated UL94 V-0. The connector includes a keying slot for alignment and polarization.
With a current rating of 1.75A per contact and an operating temperature range of -55°C to 105°C, this header is suitable for general-purpose interconnection in controlled environments.
| Qty | Low | High |
|---|---|---|
| 1+ | $4.39 | $4.39 |
| 10+ | $3.73 | $3.73 |
| 25+ | $3.65 | $3.65 |
| 100+ | $3.55 | $3.55 |
| 250+ | $3.45 | $3.45 |
| 336+ | $2.73 | $2.73 |
| 1,008+ | $2.70 | $2.70 |
| 2,688+ | $2.69 | $2.69 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 2.54mm (0.100").
30 positions total in 2 rows, all positions loaded.
1.75A per contact.
