| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Form Factor | |
| Height | |
| Input Connector | |
| Input Frequency | |
| Input Type | |
| Input Voltage | |
| Length | |
| Medical Grade | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Power (Watts) | |
| Region Utilized | |
| Relative Humidity | |
| Storage Temperature | |
| Voltage | |
| Weight | |
| Width |
The Inventus Power MWA220012A-13A is a 220 Watt Class I medical desktop power supply. It operates with an input voltage range of 85-264VAC and provides a stable 12V output at 18.3A.
This power supply meets stringent medical and EMC safety standards, including EN60601-1 Class I 3.1 Edition and IEC/EN 60601-1-2 4th edition. It boasts Level V efficiency, with typical efficiency reaching 89% at 115VAC. Key electrical protections include over-voltage, over-temperature, over-current, and short-circuit protection with auto-restart.
Designed for reliability, the MWA220012A-13A offers a lifetime expectation of over 5 years and comes with a 5-year limited warranty. Its compact desktop form factor measures 208.0mm x 73.1mm x 39.5mm, facilitating integration into various medical equipment setups. The unit utilizes natural convection cooling and has an IPX1 rating for protection against dripping water.
The output voltage is 12V.
The output current is 18.3A.
The power rating is 220W.
It meets Level V efficiency.
The operating temperature range is 0°C to 60°C.
It complies with EN60601-1 Class I 3.1 Edition and IEC/EN 60601-1-2 4th edition.
It comes with a 5-year limited warranty.
