| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Height | |
| Input Connector | |
| Input Type | |
| Input Voltage | |
| Length | |
| Medical Grade | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Output Current | |
| Output Voltage | |
| Polarization | |
| Power (Watts) | |
| Region Utilized | |
| Tape & Reel | |
| Voltage | |
| Width |
This AC/DC wall mount adapter, part number MW172KB0903B01 from SL Power Electronics, delivers a stable 9V output with a maximum current of 2A, totaling 18W of power. Designed for use in North America, it accepts input voltages ranging from 100 to 240 VAC and features a fixed blade input connector, with multi-blade options sold separately.
The adapter operates within a temperature range of 0°C to 40°C and boasts Level IV efficiency. Its output is delivered through a standard barrel plug (2.5mm I.D. x 5.5mm O.D. x 9.5mm) with positive center polarization. The compact dimensions are 84.6mm x 46.0mm x 33.0mm.
This unit is specifically suited for medical applications and holds CE and cULus approval agency certifications. It complies with RoHS3 standards and has an MSL rating of 1.
The adapter outputs 9 volts DC at a maximum current of 2 amperes.
It accepts an alternating current input ranging from 100 to 240 volts.
It uses a positive center barrel plug with a 2.5mm inner diameter and 5.5mm outer diameter.
The unit is rated for operation between 0 degrees Celsius and 40 degrees Celsius.
It is designed as a Class II wall mount adapter that plugs directly into a standard outlet.
The adapter provides a maximum continuous output power of 18 watts.
No, it utilizes Class II insulation, which provides double or reinforced protection without a ground wire.
