This AC/DC desktop adapter from SL Power Electronics, part number MW172KB0503F01, provides a reliable 5V output with a maximum current of 3A, delivering a total of 15W of power. Designed for international use, it accepts input voltages from 100 to 240 VAC and features a Level IV efficiency rating, ensuring optimal power consumption with a maximum no-load power draw of 500mW.
The adapter operates within a temperature range of 0°C to 40°C and has dimensions of 84.6mm x 46.0mm x 33.0mm. It utilizes a standard IEC 320-C14 input connector and a 2.5mm I.D. x 5.5mm O.D. x 9.5mm barrel plug for output. The positive center polarization is standard for this type of connector.
With approvals including CE and cULus, this adapter is suitable for medical applications. The input cord is sold separately, allowing for flexible integration into various system designs. Its desktop (Class I) form factor makes it a versatile power solution.
The adapter provides a regulated 5V DC output capable of supplying up to 3A of current.
The unit operates on an alternating current input ranging from 100 to 240 VAC.
The device is rated for continuous operation between 0°C and 40°C.
It uses an IEC 320-C14 socket for AC input and a 2.5mm inner diameter by 5.5mm outer diameter barrel plug for DC output.
The power cord is sold separately and must be purchased independently.
The enclosure dimensions are 84.6mm in length, 46.0mm in width, and 33.0mm in height.
