| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
48 pcs
|
48 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Halogen Free | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination |
The Samtec MTMM-120-11-S-D-385 is a 40-position unshrouded header strip from the MTMM series. It features a 2.00mm pitch and is designed for through-hole mounting with solder termination. The contacts are made of phosphor bronze with a tin finish (30.0µin) and have a square shape. The insulation is black liquid crystal polymer (LCP) with a UL94 V-0 flammability rating. The overall contact length is 15.09mm, with a post height of 9.78mm (0.385 inches). The header is unshrouded with a push-pull fastening type, suitable for board-to-board or cable applications. It is rated for 3A per pin and operates over a temperature range of -55°C to 125°C. The component is RoHS3 compliant, REACH unaffected, and MSL Level 1. Packaging is bulk. The MTMM series offers flexible post height options, and this variant has a 0.385-inch post height. It mates with several Samtec socket strips such as the CLT, ESQT, MMS, SMM, SQT, SQW, TLE, and TCSD series.
| Qty | Low | High |
|---|---|---|
| 1+ | $8.39 | $8.39 |
| 2+ | $83.70 | $83.70 |
| 10+ | $7.95 | $7.95 |
| 20+ | $80.39 | $80.39 |
| 25+ | $7.15 | $7.15 |
| 50+ | $6.61 | $6.61 |
| 100+ | $77.20 | $77.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 40 positions.
The pitch is 2.00mm.
The current rating is 3A.
Through hole mounting.
-55°C to 125°C.
Tin with 30.0µin (0.76µm) thickness.
Yes, RoHS3 compliant.
