The Inventus Power MTB080012A is an 80 Watt Class I medical open frame AC-DC power supply. It is designed for demanding medical applications, featuring universal input voltage ranging from 85 to 264 VAC.
This power supply delivers a continuous output of 80W with a 12V output voltage and a maximum current of 6.7A. It boasts a high efficiency of 90% and meets Level V efficiency standards. The unit operates within a temperature range of -20°C to 70°C with derating.
Key compliance includes Medical Approval to IEC/EN60601-1 Class I 3.2 Edition and EMC safety to IEC/EN 60601-1-2 4.1 Edition. It also holds CB, CE, and cTUVus approvals. The open frame form factor and chassis mount type make it suitable for internal integration into systems.
Dimensions are 101.6mm x 50.8mm x 25.7mm. The MTB080012A is part of the MTB080 Series and is manufactured by Inventus Power under the Elpac Power Systems brand.
The MTB080012A provides an 80W power output.
The input voltage range is 85 to 264 VAC.
The MTB080012A has a 12V output voltage and a maximum current of 6.7A.
The operating temperature range is -20°C to 70°C with derating.
The dimensions are 101.6mm in length, 50.8mm in width, and 25.7mm in height.
It meets Medical Approval to IEC/EN60601-1 Class I 3.2 Edition and EMC safety to IEC/EN 60601-1-2 4.1 Edition.
The power supply complies with Level V efficiency.
