MSTBVA2,5/2G The Phoenix Contact MSTBVA 2,5/ 2-G-RN is a 2-position PCB header designed for wave soldering. It offers a nominal current of 12A and a rated voltage of 320V (III/2).
Mfr Part #:

MSTBVA2,5/2G

Available from 1 distributors
Mfr Name: Phoenix Contact
Phoenix Contact
The Phoenix Contact MSTBVA 2,5/ 2-G-RN is a 2-position PCB header designed for wave soldering. It offers a nominal current of 12A and a rated voltage of 320V (III/2).
✓ Total Stock: 150 pcs
$ Price Range: $1.00

MSTBVA2,5/2G Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
MW.FEP S.p.A. ✓
Non-Authorised Inventory information
150 pcs
On Request
150 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MSTBVA2,5/2G Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Contact Material
Lead Style
Mounting Feature
Mounting Type
Number of Positions
Number of Rows
Pitch
View Similar Products (0)

MSTBVA2,5/2G Description

Short technical summary and product information.

This Phoenix Contact MSTBVA 2,5/ 2-G-RN is a high-quality PCB header from the COMBICON MSTB 2,5 plug-in system. It features a 5 mm pitch and a 2.5 mm² nominal cross section, suitable for wave soldering mounting.



The header is designed with 2 positions and 1 row, providing a nominal current rating of 12A and a rated voltage of 320V (III/2). It utilizes a pin contact connection type with a tin-plated Cu alloy contact material for reliable performance. The locking mechanism is a snap-in type with an engagement nose for secure connection.



Key electrical parameters include a rated voltage (III/3) of 250V and (II/2) of 400V, along with rated surge voltages of 4kV for all configurations. The pin layout is linear, and the solder pin length is 3.9 mm. This component is designed for maximum flexibility in device design, offering a well-known mounting principle for worldwide use and vertical connection for multi-row arrangement on the PCB.



Packaged in cardboard, this header is part of the MSTBVA series, known for its closed contour for optimum stability and an intuitive locking mechanism to prevent accidental disconnection. The surface is tin-plated, with specific tin and nickel layers on the contact areas.

MSTBVA2,5/2G Quick Information

Product Type: PCB header
Series: MSTBVA 2,5/..-G-RN
Canonical Name: Phoenix Contact MSTBVA 2,5/ 2-G-RN PCB header
Subcategory: PCB Headers

MSTBVA2,5/2G Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

MSTBVA2,5/2G Estimated Pricing

Qty Low High
1+ $1.00 $1.00

Estimated market price range - modelled values for guidance only, not live distributor offers.

MSTBVA2,5/2G Features

  • 2-position PCB header for wave soldering.
  • 12A nominal current and 320V rated voltage (III/2).
  • 5mm pitch with 2.5mm² nominal cross section.
  • Snap-in locking with engagement nose.
  • Tin-plated Cu alloy contacts for durability.

MSTBVA2,5/2G Applications

  • Ideal for PCB terminal block connections.
  • Suitable for industrial control panels.
  • Used in automation and robotics systems.
  • Enables multi-row arrangement on PCBs.

MSTBVA2,5/2G FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the MSTBVA2,5/2G have?

The MSTBVA2,5/2G has 2 positions.

What is the pitch of this connector?

The pitch is 5 mm.

What is the nominal current rating?

The nominal current rating is 12 A.

What are the rated voltages for the MSTBVA2,5/2G?

Rated voltages are 400 V (II/2), 320 V (III/2), and 250 V (III/3).

What mounting type does the MSTBVA2,5/2G use?

Wave soldering mounting with an engagement nose feature.

Which plug-in system is this header compatible with?

COMBICON MSTB 2,5.

What contact surface and material does it use?

Tin-plated Cu alloy contacts with a tin top layer.
