| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Frequency | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Package / Case | |
| Power (Watts) | |
| Relative Humidity | |
| Standard Number | |
| Storage Temperature | |
| Type | |
| Voltage | |
| Weight | |
| Width |
The Astrodyne TDI MSSA-0101/C is a 10W medical-grade, ultraminiature switching power supply. It is designed for board mounting and features a universal 90 to 264VAC input voltage range.
This AC/DC converter provides a single 5VDC output with a maximum current of 2A, delivering 10W of power. Key electrical specifications include 4000VAC input-to-output isolation, typical efficiency of 75-80%, and a leakage current of less than 500uA at 264VAC.
Designed for reliability, the MSSA-0101/C operates within a temperature range of 0°C to +50°C and has an MTBF of 180,000 hours. It is housed in an encapsulated, PCB mount package with through-hole termination.
This power supply is suitable for medical applications and carries approvals from CE, cURus, and TUV, including compliance with EN60601-1.
The output voltage is 5 VDC.
The input voltage range is 90 to 264 VAC.
The maximum output current is 2A.
The power rating is 10W.
The operating temperature range is 0°C to 50°C.
It is an enclosed, 10-DIP Module, 6 Leads package designed for through hole mounting.
