| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
310 pcs
|
310 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current Rating | |
| Current Saturation | |
| DC Resistance | |
| Inductance | |
| Mounting Type | |
| Operating Temperature | |
| SVHC Present | |
| Self Resonant Frequency | |
| Shielding | |
| Tolerance | |
| Type |
The Coilcraft XGL1010-222MED is a high-performance shielded molded inductor designed for demanding applications. It offers an inductance value of 2.2µH with a tolerance of ±20% and a significant current rating of 24.6A. The inductor exhibits a low DC resistance of 2.6mOhm Max, contributing to efficient operation.
This component features a metal composite core and a shielded construction, minimizing electromagnetic interference. It is designed for surface mounting and operates within a temperature range of -40°C to 125°C. The self-resonant frequency is 25MHz, making it suitable for various frequency-dependent circuits.
The inductor is packaged in Tape & Reel (TR) format, suitable for automated assembly processes. Its nonstandard package size is specified as 0.445" L x 0.". The RoHS status is RoHS3 Compliant, and the Moisture Sensitivity Level (MSL) is 1 Unlimited.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.19 | $0.19 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
2.2 µH (measured at 1 MHz).
±20%
24.6 A
36 A
2.6 mΩ
25 MHz
Nonstandard
