| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Length | |
| Medical Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Mean Well USA MSP-450-48 is an enclosed AC/DC converter designed for robust performance. It provides a single output of 48V with a maximum current of 9.5A, delivering a total power of 456W. This unit features adjustable output, power factor correction (PFC), and universal input, making it versatile for various applications.
The converter is built for chassis mounting and operates within a temperature range of -40°C to 70°C, with derating. Its dimensions are 218.0mm in length, 105.0mm in width, and 41.0mm in height. Key features include remote on/off and remote sense capabilities, along with an efficiency rating of 89.5%.
This AC/DC converter is approved by CB, CE, and cURus, indicating compliance with various safety and performance standards. It is suitable for applications requiring reliable power conversion, particularly in medical fields.
The MSP-450-48 provides a single output of 48V at 9.5A.
The MSP-450-48 is rated for 456W.
The MSP-450-48 has an efficiency of 89.5%.
The MSP-450-48 operates from -40°C to 70°C with derating.
The MSP-450-48 uses chassis mount.
The MSP-450-48 measures 218.0mm in length, 105.0mm in width, and 41.0mm in height.
The MSP-450-48 is approved by CB, CE, and cURus.
