The Mean Well USA MSP-300-15 is an enclosed AC/DC converter designed for demanding applications, particularly in the medical field. It provides a robust 330W of power with a single 15V output.
Key electrical specifications include a universal input voltage range, 88% efficiency, and an isolation voltage of 4 kV. The converter is equipped with features such as adjustable output, power factor correction (PFC), and remote on/off functionality, enhancing its versatility and integration into various systems.
Mechanically, the MSP-300-15 is designed for chassis mounting, with dimensions of 199.0mm x 105.0mm x 41.0mm. It operates within a wide temperature range of -40°C to 70°C, with derating applied at higher temperatures. The unit is approved by CB, CE, cURus, and TUV, ensuring compliance with international safety standards.
Environmental compliance includes RoHS3 compliance and an MSL of 1, indicating suitability for a broad range of manufacturing processes. Its REACH status is unaffected.
The MSP-300-15 provides a 15V output.
The MSP-300-15 is rated for 330W.
The MSP-300-15 has an efficiency of 88%.
The MSP-300-15 provides 4 kV isolation.
The MSP-300-15 operates from -40°C to 70°C with derating.
The MSP-300-15 is designed for chassis mounting.
The MSP-300-15 is approved by CB, CE, cURus, and TUV.
