| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Medical Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Type | |
| Voltage |
The Inventus Power MSM0705 is a 7W open frame AC/DC power supply designed for medical applications. It provides a regulated 5.1V DC output with a current rating of 1.4A and a peak current of 2.0A. The unit accepts a wide input voltage range of 85-264VAC, making it versatile for global use.
Key electrical specifications include a total regulation of ±5%, an efficiency of 77%, and a hold-up time exceeding 22ms. Safety features include over-voltage protection at 110-135% and over-current protection at 200-350%. It also features short circuit protection with auto-restart.
With dimensions of 57.9mm x 50.8mm x 18.1mm, this open frame converter is suitable for chassis mounting. The operating temperature range is 0°C to 50°C. Compliance includes CB, CE, and UL certifications, along with emissions standards like FCC Part 15 Class B and CISPR11.
The MSM0705 provides a 5.1V output voltage at 1.4A.
The input voltage range is 85-264VAC.
The power rating is 7W.
The operating temperature range is 0°C to 50°C.
The dimensions are 57.9mm x 50.8mm x 18.1mm.
It is approved by CB, CE, and UL.
The hold-up time is greater than 22ms at full load.
