MSL0201RGBW1 The ROHM Semiconductor MSL0201RGBW1 is a diffused RGB LED in a PICOLED package. It features a right-angle surface mount design and common anode configuration.
Mfr Part #:

MSL0201RGBW1

Available from 1 distributors
Mfr Name: ROHM Semiconductor
ROHM Semiconductor
The ROHM Semiconductor MSL0201RGBW1 is a diffused RGB LED in a PICOLED package. It features a right-angle surface mount design and common anode configuration.
✓ Total Stock: 5,065 pcs
$ Price Range: $0.06

MSL0201RGBW1 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
5,065 pcs
On Request
5065 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MSL0201RGBW1 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Configuration
Current
Height (Max)
Lens Color
Lens Style
Lens Transparency
Millicandela Rating
Mounting Type
Supplier Device Package
Tape & Reel
Voltage
Wavelength
View Similar Products (0)

MSL0201RGBW1 Description

Short technical summary and product information.

The ROHM Semiconductor MSL0201RGBW1 is a versatile RGB LED designed for discrete indication applications. It offers individual color control with forward voltages of 2.1V for Red, 3V for Green, and 2.9V for Blue, each rated for a nominal current of 5mA.



This LED features a diffused lens with a white lens color, providing a clear and distinct light output. The lens style is a rectangle with a flat top, measuring 3.00mm in length and 1.30mm in width. The component is housed in a 4-SMD, No Lead package, specifically a PICOLED type, suitable for right-angle surface mounting.



Key optical characteristics include dominant wavelengths of 624nm for Red, 527nm for Green, and 470nm for Blue. The luminous intensity ratings are 25mcd for Red, 90mcd for Green, and 22mcd for Blue. The maximum height of the component is 0.43mm, making it suitable for space-constrained designs.

MSL0201RGBW1 Quick Information

Product Type: RGB LED
Canonical Name: MSL0201RGBW1 RGB LED
Subcategory: Discrete LED

MSL0201RGBW1 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

MSL0201RGBW1 Estimated Pricing

Qty Low High
1+ $0.06 $0.06

Estimated market price range - modelled values for guidance only, not live distributor offers.

MSL0201RGBW1 Features

  • Diffused RGB LED in PICOLED package.
  • Common anode configuration for color control.
  • Right-angle surface mount design.
  • Individual color voltage and current ratings.
  • Specific dominant wavelengths for each color.

MSL0201RGBW1 Applications

  • Ideal for status indication.
  • Suitable for compact indicator lights.
  • Used in control panel signaling.
  • Applicable for visual feedback systems.

MSL0201RGBW1 FAQs

6 frequently asked questions generated from this part’s specifications.
What are the forward voltage ratings for the MSL0201RGBW1 LED?

The forward voltage ratings are 2.1V for Red, 3V for Green, and 2.9V for Blue.

What is the current rating for each color on the MSL0201RGBW1 LED?

The current rating for Red, Green, and Blue is 5mA per color.

What are the dominant wavelengths for the Red, Green, and Blue LEDs?

The dominant wavelengths are 624nm for Red, 527nm for Green, and 470nm for Blue.

What is the luminous intensity for each color on the MSL0201RGBW1 LED?

The luminous intensity is 25mcd for Red, 90mcd for Green, and 22mcd for Blue.

What type of package is the MSL0201RGBW1 LED in?

The MSL0201RGBW1 LED is in a 4-SMD, No Lead package, specifically a PICOLED type.

How is the MSL0201RGBW1 LED mounted?

The MSL0201RGBW1 LED is designed for surface mount, right-angle mounting.
