The Inventus Power MS6515F is an open-frame AC/DC converter designed for medical applications, delivering 65W of power with a single 15V output. It boasts a high efficiency of 86% and accepts a wide input voltage range of 85-264 VAC, making it suitable for global use.
This converter features a chassis mount design and operates within a temperature range of 0°C to 50°C. Key electrical specifications include an output current of 4.3A and a total regulation of ±5%. The unit also provides a hold-up time of 12ms at full load and 115VAC.
Safety approvals include CB and CE marking, indicating compliance with relevant standards for medical equipment. The dimensions are 127.0mm x 76.0mm x 29.2mm.
The MS6515F provides a single output voltage of 15V.
The maximum output current for the MS6515F is 4.3A.
The MS6515F has a power rating of 65W.
The efficiency of the MS6515F is 86%.
The MS6515F operates within a temperature range of 0°C to 50°C.
The MS6515F is approved by CB and CE.
The hold-up time for the MS6515F is 12ms at full load and 115VAC.
