| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
8 pcs
|
8 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Connector Type | |
| Contact Finish | |
| Fastening Type | |
| Lead Style | |
| Military Grade | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Orientation | |
| Primary Material | |
| Shell Finish | |
| Shell Material | |
| Shell Size | |
| Shielding | |
| Termination |
The MS3475W12-10P is a MIL-DTL-26482 Series 2 circular connector plug manufactured by Conesys. It features a 10-position male pin insert with gold-plated contacts for reliable signal integrity. The connector uses a bayonet lock coupling mechanism and is designed for free-hanging (in-line) mounting.
The shell is constructed from aluminum alloy with an olive drab cadmium finish, providing durability and environmental resistance. The connector is shielded and operates over a temperature range of -55°C to 200°C. Termination is via crimp contacts, which are rear-removable for easy assembly and maintenance.
This plug is intermountable and interchangeable with MIL-DTL-26482 Series 1 connectors and is widely used in commercial, military, and aerospace systems requiring general-purpose miniature cylindrical bayonet coupling connectors.
It is a plug with male pins.
It has 10 positions.
Free hanging (in-line) mounting.
Crimp termination.
-55°C to 200°C.
Olive drab cadmium.
