The ITT Cannon MS3106F28-9S is a circular connector plug from the MS A&B series, designed to meet MIL-C-5015 performance requirements. It features 12 female socket contacts arranged in a normal orientation within a free-hanging (in-line) housing. The connector uses a threaded coupling mechanism for secure mating and is terminated via solder cups, which are preloaded in the insulator and remain properly oriented during wiring.
The shell is constructed from aluminum alloy with an olive drab cadmium finish, providing corrosion resistance and durability. The contacts are machined from copper alloy and plated with silver for reliable electrical performance. The connector is rated for 900VAC and 1250VDC, with a current rating of 22A and 41A depending on contact size. It operates over a temperature range of -55°C to 125°C and is environment resistant.
Additional features include a cable clamp and coupling nut for strain relief. The connector accommodates wire sizes from 0 to 20 AWG and is rated for a minimum of 500 mating cycles. This plug is suitable for industrial controls, test equipment, traffic signals, and bus systems.
12 positions with female socket contacts.
900VAC and 1250VDC.
22A and 41A depending on contact size.
-55°C to 125°C.
Solder cup termination.
Free hanging (in-line).
Aluminum alloy shell with olive drab cadmium finish.
