| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
120 pcs
|
120 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Material | |
| SVHC Present | |
| Thread Size |
The MS25082-C19 is a hexagon nut from QPL, designed for various mechanical applications. It features a nominal thread size of 0.500 inches with a 28 threads per inch (UNEF) thread series and a 2B thread class. The nut height ranges from 0.104 to 0.114 inches, with a width across flats between 0.609 and 0.640 inches.
Constructed from various steel compositions including 304L, 316L, 302, 347, 321, 317, 316, 310, 309, 305, and 304, this nut meets QQ-S-763 federal specifications. It is passivated with a surface treatment conforming to QQ-P-35 federal specifications. The bearing surface is chamfered for ease of assembly.
This component is RoHS3 compliant and has a Moisture Sensitivity Level (MSL) of 1. The REACH status is unaffected. Manufacturer certifications are available with orders.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.00 | $1.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal thread size is 0.500 inches.
The thread series is UNEF with 28 threads per inch, and the thread class is 2B.
The nut height is between 0.104 and 0.114 inches, and the width across flats is between 0.609 and 0.640 inches.
Available materials include Steel Comp 304L, 316L, 302, 347, 321, 317, 316, 310, 309, 305, and 304, meeting QQ-S-763 specifications.
The surface treatment is passivate, conforming to QQ-P-35 federal specifications.
