MS25036-103
Molex
The Molex MS25036-103 is a ring tongue terminal designed for regular wire types. It offers a closed barrel design and insulation support.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
92 pcs
|
92 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Finish | |
| Insulation | |
| Insulation Diameter | |
| Length | |
| Material | |
| Shape | |
| Voltage Rating |
The KAYTECH I MS25036-103 is an insulated ring tongue terminal from the PIDG series. It features a closed barrel design and is suitable for regular wire types within a 22-16 AWG range.
This terminal has a copper material with a tin finish and a red nylon insulation sleeve. The insulation diameter ranges from 2.03 to 3.18 mm, and it supports a stud size of 10 with a stud diameter of 5.00 mm. The tongue material thickness is 0.79 mm.
Electrically, the MS25036-103 is rated for 300 VAC. Its overall length is 21.44 mm. The terminal is compliant with RoHS and ELV standards. It is supplied in loose piece packaging with a standard quantity of 1,000 units.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.00 | $1.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The wire range for the MS25036-103 terminal is 22-16 AWG.
The voltage rating of the MS25036-103 terminal is 300 VAC.
The MS25036-103 terminal is made of copper with a tin finish.
The MS25036-103 terminal features nylon insulation.
The MS25036-103 terminal is packaged as a loose piece with a quantity of 1,000 units.
