MS-352-051-345-220S

The AirBorn MS-352-051-345-220S is a D-Sub micro-D connector plug with 51 male pin contacts arranged in 3 rows. It is designed for signal applications requiring a compact, high-density interconnect solution.

The connector features a 0.050 inch pitch with 0.050 inch row-to-row spacing, resulting in a high-density layout. Contacts are gold plated with a thickness of 50.0 microinches (1.27 micrometers) for reliable signal integrity and corrosion resistance. The shell is made of aluminum alloy with electroless nickel plating, providing durability and EMI shielding. The flange includes female screwlocks (2-56) on the mating side for secure attachment.

Mounting is through hole, right angle orientation, allowing for perpendicular PCB placement. Termination is via solder connections, suitable for wave soldering processes. The backset spacing is 0.150 inches (3.81mm), which accommodates standard PCB thicknesses.

This connector is suitable for aerospace, military, and industrial applications where robust, reliable connections are required in limited space. The 3-amp current rating per contact supports moderate signal and power needs. The metal shell and electroless nickel finish provide good environmental resistance.
