| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Form | |
| Height | |
| Input Connector | |
| Input Type | |
| Length | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Power (Watts) | |
| Region Utilized | |
| Standard Number | |
| Voltage | |
| Width |
The Phihong USA MQ05A-050AW-H is a compact AC/DC wall mount adapter designed for medical applications. It delivers a stable 5VDC output with a maximum current of 1A, providing a total power of 5W.
This adapter complies with Level VI energy efficiency standards and CoC Tier 2 requirements, ensuring reduced energy consumption. It is certified by multiple approval agencies including ANSI/AAMI, cSGSus, ES, IEC, and PSB, making it suitable for demanding medical device requirements. The adapter features a NEMA 1-15P input connector for North American outlets and a USB A receptacle for output.
With an operating temperature range of 0°C to 40°C, the MQ05A-050AW-H is built for reliable performance in various environments. Its dimensions are 37.9mm in length, 22.3mm in width, and 47.0mm in height. The device operates with a low no-load power consumption of a maximum of 30mW.
The MQ05A-050AW-H adapter provides a 5VDC output at 1A.
The power rating of the MQ05A-050AW-H adapter is 5W.
The MQ05A-050AW-H adapter meets Level VI efficiency and CoC Tier 2 standards.
The adapter operates within a temperature range of 0°C to 40°C.
The MQ05A-050AW-H uses a NEMA 1-15P input connector.
The output connector is a USB A Receptacle.
The MQ05A-050AW-H adapter is RoHS3 Compliant.
