| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5,000 pcs
|
5000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
2,597 pcs
|
2597 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
2,020 pcs
|
2020 pcs | On Request | 1 | On Request | On Request | 24+ | On Request | On Request | |
|
30 pcs
|
30 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Accuracy | |
| Applications | |
| Features | |
| Maximum Pressure | |
| Mounting Type | |
| Operating Pressure | |
| Operating Temperature | |
| Output | |
| Output Type | |
| Port Size | |
| Port Style | |
| Pressure Type | |
| Termination Style | |
| Voltage |
The NXP Semiconductors MPX5700DP is a differential pressure sensor suitable for board mounting applications. This sensor provides an analog voltage output and features temperature compensation for stable performance.
Key electrical specifications include an operating pressure range of 700 kPa and a maximum pressure of 2800 kPa. The sensor operates with a supply voltage of 4.75V to 5.25V, outputting a voltage between 0.2V and 4.7V. Its accuracy is rated at ±2.5%.
The operating temperature range for this device is -40°C to 125°C, making it suitable for various environmental conditions. The port features a barbed style with a dual tube connection, measuring 4.93mm (0.19").
Packaged in a 6-SIP module with through-hole mounting and PC pin termination, the MPX5700DP is designed for integration into electronic circuits.
The operating temperature range is -40°C to 125°C.
The accuracy is ±2.5%.
The operating pressure is 700 kPa.
It provides an Analog Voltage output.
The package is a 6-SIP Module with Through Hole mounting.
The RoHS status is Compliant.
