| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
40,000 pcs
|
40000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
1,834 pcs
|
1834 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Features | |
| Maximum Pressure | |
| Mounting Type | |
| Operating Pressure | |
| Operating Temperature | |
| Output | |
| Output Type | |
| Port Size | |
| Port Style | |
| Pressure Type | |
| Termination Style | |
| Voltage |
The NXP Semiconductors MPX2100AP is an absolute pressure sensor designed for board mounting applications. It features a Wheatstone Bridge output, providing a nominal output of 0 mV to 40 mV with a 10V supply.
This sensor operates within a voltage range of 10V to 16V and can withstand a maximum pressure of 400 kPa, with an operating pressure of 100 kPa. The operating temperature range is from -40°C to 125°C, ensuring reliable performance in various environmental conditions. The MPX2100AP is temperature compensated for accuracy.
Designed with a Through Hole mounting type, this sensor utilizes a 4-SIP module package. The termination style is PC Pin, and it features a barbed port style for connection. The sensor is RoHS3 compliant and has a Moisture Sensitivity Level (MSL) of 1 Unlimited.
Key specifications include an operating pressure of 14.5 PSI (100 kPa) and a maximum pressure of 58.02 PSI (400 kPa). The output type is a Wheatstone Bridge, delivering a 0 mV to 40 mV output signal.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.50 | $1.50 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The MPX2100AP has an operating pressure of 14.5 PSI (100 kPa).
The maximum pressure is 400 kPa (58.02 PSI).
It operates between 10V and 16V.
It provides a Wheatstone Bridge output.
It operates from -40°C to 125°C.
RoHS3 compliance status is unverified.
