The Mean Well USA MPS-200-24 is an open frame AC/DC converter designed for chassis mounting. It provides a power output of 142W, with a maximum of 202W under forced air conditions, and delivers 24V.
Key electrical specifications include a voltage rating of 4000V (4kV), a current output of 5.9A, and an efficiency of 86%. This converter is equipped with features such as adjustable output, remote on/off, remote sense, and universal input, making it versatile for various applications.
Designed for demanding environments, it operates within a temperature range of -20°C to 70°C with derating. The unit has dimensions of 177.8mm in length, 107.2mm in width, and 35.6mm in height. It holds approvals from CB, CE, cURus, and TUV.
This converter is specifically suited for medical applications and features a single output. Its open frame construction facilitates integration into systems requiring a compact and efficient power solution.
The MPS-200-24 provides a 24V output and has a power rating of 142W, with up to 202W under forced air.
Key features include adjustable output, remote on/off, remote sense, and universal input.
The operating temperature range is -20°C to 70°C, with derating applied.
It is approved by CB, CE, cURus, and TUV.
The dimensions are 177.8mm in length, 107.2mm in width, and 35.6mm in height.
The efficiency is 86%.
