| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Isolation | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Package / Case | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Mean Well USA MPM-45-5 is an open-frame AC/DC converter designed for various applications, including medical and household appliances. It delivers 40W of power with a single 5V output at 8A.
This converter operates within a wide input voltage range of 80-264VAC or 113-370VDC, offering flexibility in power source selection. It boasts an efficiency of 88% and features a compact size with Through Hole mounting.
Key features include medical safety approvals (2 x MOPP), extremely low leakage current (<0.1W no load power consumption), and a wide operating temperature range of -30°C to 80°C. Protections include short circuit, overload, and over voltage.
The MPM-45-5 is built with Isolation Class II and comes with a 3-year warranty. It meets EMI Class B standards without additional components.
The MPM-45-5 accepts 80-264 VAC or 113-370 VDC input.
It provides a single 5 V output at 8 A, for 40 W total output power.
The operating temperature range is -30°C to 80°C with derating.
The MPM-45-5 comes in a 4-DIP module package with through-hole mounting.
The MPM-45-5 is rated at 88% efficiency, with no-load power consumption below 0.1 W.
It provides 4000 VAC input-to-output isolation, 100 MOhms isolation resistance at 500 VDC, and 2xMOPP primary-to-secondary isolation.
The MPM-45-5 meets Class B EMI requirements.
