| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| No Load Power Consumption | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| SVHC Present | |
| Type | |
| Voltage | |
| Weight | |
| Width |
The Mean Well MPM-45-24ST is a high-density, small-size AC/DC converter designed for various applications. It features a wide input voltage range of 80V AC to 264V AC and delivers a stable 24V DC output at 1.88A, providing up to 45W of power. The converter boasts a high efficiency of 92.5% and operates within a temperature range of -30°C to 80°C with derating.
With a chassis mount type and enclosed design, the MPM-45-24ST is suitable for integration into systems requiring reliable power conversion. Its dimensions are 109.0mm in length, 52.0mm in width, and 33.5mm in height. The unit has a single output and is designed for applications including household appliances and medical equipment.
Key electrical characteristics include extremely low leakage current and no minimum load requirement, contributing to its energy efficiency with a no-load power consumption of less than 0.1W. The device meets various safety and compliance standards, indicated by approvals such as CB, CE, cURus, EAC, and TUV.
The output voltage is 24V dc.
The maximum output current is 1.88A.
The power rating is 45W, with a 50W rating under forced air conditions.
The input voltage range is 80V ac to 264V ac.
The operating temperature range is -30°C to 80°C, with derating.
The dimensions are 109.0mm in length, 52.0mm in width, and 33.5mm in height.
No, it has no minimum load requirement.
