The MP2607DL-C513-LF-Z from Monolithic Power Systems is a linear lithium-ion battery charger IC designed for single-cell applications. It integrates system power path management, allowing it to power the system from an AC adapter or USB while simultaneously charging the battery. The device supports multiple charging stages including trickle charge, constant current (CC), and constant voltage (CV) regulation, along with charge termination and status indication.
The power path management ensures continuous system supply by automatically selecting the power source from input, battery, or both. It includes a low-dropout regulator from the input to the system and a 50mΩ switch from the battery to the system. This separation of charging current and system load current allows for proper charge termination and keeps the battery fully charged. The MP2607DL-C513-LF-Z is housed in a 14-pin, 3mm x 4mm QFN package, suitable for space-constrained designs.
This IC is ideal for applications requiring efficient battery charging and system power management. Its integrated features simplify design and reduce component count, making it a versatile solution for portable electronics and other battery-powered devices.
The MP2607DL-C513-LF-Z is a linear lithium-ion battery charger IC.
It is designed for single-cell lithium-ion/lithium-polymer batteries.
Yes, the MP2607DL-C513-LF-Z integrates system power path management.
It supports trickle charge, constant current (CC), and constant voltage (CV) charging.
The MP2607DL-C513-LF-Z is supplied in a 14-pin, 3mm x 4mm QFN package.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) is 1 Unlimited.
