| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
139,077 pcs
|
139077 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Input Type | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Channels | |
| Operating Temperature | |
| Output Type | |
| Supplier Device Package | |
| Vce Saturation (Max) |
The Vishay Semiconductor Opto Division MOC8104 is a transistor output optoisolator designed for signal isolation applications. It provides a high isolation voltage of 5300Vrms, making it suitable for applications requiring robust electrical separation.
Key electrical characteristics include a typical forward voltage of 1.25V and a maximum DC forward current of 60 mA. The output transistor can handle up to 30V and 50mA per channel. Switching times are typically 3µs for turn-on and 2.3µs for turn-off, with rise and fall times of 2µs.
This component is housed in a 6-SMD, Gull Wing package, suitable for surface mounting. The operating temperature range is from -55°C to 100°C. The MOC8104 is RoHS3 Compliant, indicating adherence to environmental standards.
With its reliable isolation and transistor output, the MOC8104 is a versatile component for various electronic designs requiring signal integrity and protection.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The MOC8104 optoisolator provides 5300Vrms of isolation voltage.
The MOC8104 features a transistor output.
The typical turn-on time is 3µs and the typical turn-off time is 2.3µs.
The MOC8104 operates within a temperature range of -55°C to 100°C.
The MOC8104 is designed for surface mounting.
The MOC8104 comes in a 6-SMD, Gull Wing package.
The MOC8104 is RoHS3 Compliant.
