| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
100 pcs
|
100 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Channels | |
| Operating Temperature | |
| SVHC Present | |
| Storage Temperature | |
| Supplier Device Package |
The Isocom Components MOC8102 is a transistor output optocoupler designed for signal isolation applications. It offers a high isolation voltage of 5300Vrms, making it suitable for environments requiring electrical separation.
Key electrical specifications include a typical forward voltage of 1.15V and a maximum DC forward current of 60mA. The output stage can handle up to 50mA with a maximum Vce saturation of 400mV. Current transfer ratios range from a minimum of 73% at 10mA to a maximum of 117% at 10mA. Typical rise and fall times are 2µs.
This optocoupler is housed in a standard 6-DIP package and is designed for through-hole mounting. It operates within a temperature range of -55°C to 100°C. The device is specified with a maximum output voltage of 30V.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The MOC8102 offers an isolation voltage of 5300Vrms.
The MOC8102 has a transistor output.
The MOC8102 is available in a 6-DIP package.
The MOC8102 operates between -55°C and 100°C.
The typical forward voltage for the MOC8102 is 1.15V.
The MOC8102 has a maximum output current of 50mA.
The minimum current transfer ratio for the MOC8102 is 73% at 10mA.
