MOC3023XSM The Isocom Components MOC3023XSM is a surface mount optoisolator featuring a Triac output. It offers 400V peak blocking voltage and 5300Vrms isolation.
Mfr Part #:

MOC3023XSM

Available from 1 distributors
Mfr Name: Isocom Components
Isocom Components
The Isocom Components MOC3023XSM is a surface mount optoisolator featuring a Triac output. It offers 400V peak blocking voltage and 5300Vrms isolation.
✓ Total Stock: 11,154 pcs
$ Price Range: $7.60

MOC3023XSM Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Fe Components ✓
Non-Authorised Inventory information
11,154 pcs
On Request
11154 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MOC3023XSM Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Approval Agency
Current
Mounting Type
Number of Channels
Operating Temperature
Output Type
Reverse Current
Reverse Voltage
Static dV
Storage Temperature
Voltage
Zero Crossing Circuit
View Similar Products (0)

MOC3023XSM Description

Short technical summary and product information.

The Isocom Components MOC3023XSM is an optically coupled isolator designed for Triac driver applications. It consists of a Gallium Arsenide infrared emitting diode coupled with a light-activated silicon bilateral switch.



This device features a 400V peak blocking voltage and 5300Vrms isolation voltage. The input diode has a maximum forward current of 50mA and a reverse voltage of 6V. The output Triac can handle a peak forward current of 1A and has a maximum off-state output terminal voltage of 400V.



With a typical forward voltage of 1.2V and a maximum trigger current of 5mA, the MOC3023XSM is suitable for various power control applications. It operates within a temperature range of -40°C to +100°C.



The MOC3023XSM is provided in a 6-SMD, Gull Wing package, designed for surface mounting. It includes a non-zero crossing circuit.

MOC3023XSM Quick Information

Product Type: Optoisolator
Canonical Name: Isocom Components MOC3023XSM Optically Coupled Bilateral Switch Non-Zero Crossing Triac
Subcategory: Triac, SCR Output

MOC3023XSM Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

MOC3023XSM Estimated Pricing

Qty Low High
1+ $7.60 $7.60

Estimated market price range - modelled values for guidance only, not live distributor offers.

MOC3023XSM Features

  • 400V peak blocking voltage.
  • 5300Vrms input-output isolation.
  • 5mA maximum trigger current.
  • Surface mount 6-SMD package.
  • Triac output type.

MOC3023XSM Applications

  • Used as a power triac driver.
  • Suitable for motor control circuits.
  • Applicable in consumer appliances.
  • Can be used in CRT applications.
  • Designed for printer power supplies.

MOC3023XSM FAQs

6 frequently asked questions generated from this part’s specifications.
What is the peak blocking voltage of the MOC3023XSM?

The peak blocking voltage is 400V.

What is the isolation voltage for the MOC3023XSM?

The isolation voltage is 5300Vrms.

What is the maximum trigger current for the MOC3023XSM?

The maximum trigger current is 5mA.

What is the operating temperature range for this optoisolator?

The operating temperature range is -40°C to +100°C.

What package type is the MOC3023XSM supplied in?

It is supplied in a 6-SMD, Gull Wing package.

Does the MOC3023XSM have a zero crossing circuit?

No, it does not have a zero crossing circuit.
