Mfr Part #:

MMT-110-02-T-DH-K-TR

20 position dual row 2.00mm pitch surface mount right angle unshrouded header from Samtec's MMT series. Features phosphor bronze contacts with tin finish, pick and place feature, and UL94 V-0 rated LCP insulation.

✓ Total Stock: 2,524 pcs

$ Price Range: $1.47 - $2.68

MMT-110-02-T-DH-K-TR Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Components Technology Group, Inc. ✓ Non-Authorised Inventory information	2,524 pcs On Request	2524 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

MMT-110-02-T-DH-K-TR Description

Short technical summary and product information.

The Samtec MMT-110-02-T-DH-K-TR is a 20-position dual row header with a 2.00mm pitch, designed for surface mount right angle termination. This unshrouded header is part of the MMT series and features square phosphor bronze contacts with a tin finish for reliable electrical connections. The insulation is made of black Liquid Crystal Polymer (LCP) with a UL94 V-0 flammability rating, ensuring robust performance in demanding environments. It supports a current rating of 3A and operates over a temperature range of -55°C to 105°C. The header includes a pick and place feature for automated assembly. It is supplied in tape and reel packaging with 525 pieces per reel. The push-pull fastening type allows for easy mating and unmating, making it suitable for board-to-board or cable applications.

MMT-110-02-T-DH-K-TR Quick Information

Product Type: Header

Series: MMT

Canonical Name: MMT-110-02-T-DH-K-TR - 20 Position 2.00mm Pitch Dual Row Surface Mount Right Angle Unshrouded Header

Subcategory: Unshrouded Header

MMT-110-02-T-DH-K-TR Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Lead Free: Yes

MMT-110-02-T-DH-K-TR Estimated Pricing

Qty	Low	High
1+	$2.68	$2.68
50+	$2.62	$2.62
100+	$2.24	$2.24
525+	$1.73	$1.73
1,050+	$1.58	$1.58
1,575+	$1.54	$1.54
4,725+	$1.47	$1.47

Estimated market price range - modelled values for guidance only, not live distributor offers.

MMT-110-02-T-DH-K-TR Features

20 position dual row header.
2.00mm pitch for compact designs.
Surface mount right angle termination.
Unshrouded push-pull fastening type.
Pick and place compatible.

MMT-110-02-T-DH-K-TR Applications

Board-to-board interconnections.
Cable-to-board connections.
Perpendicular mating applications.
General purpose signal routing.

MMT-110-02-T-DH-K-TR FAQs

7 frequently asked questions generated from this part’s specifications.

How many positions does the MMT-110-02-T-DH-K-TR have?

20 positions.

What is the pitch of this header?

2.00 mm.

What is the current rating of the MMT-110-02-T-DH-K-TR?

3A.

What is the mounting type of this header?

Surface mount, right angle.

What is the operating temperature range?

-55°C to 105°C.

Is the header shrouded or unshrouded?

Unshrouded.

What is the insulation material and flammability rating?

Liquid Crystal Polymer (LCP) with UL94 V-0 rating.

Category	Headers, Male Pins
Manufacturer Name	Samtec Inc.
Connector Type	Header
Contact Finish	Tin
Contact Length	4.45mm (0.175")
Contact Material	Phosphor Bronze
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	3A
Fastening Type	Push-Pull
Features	Pick and Place
Halogen Free	Yes
Insulation Color	Black
Insulation Height	4.00mm (0.157")
Insulation Material	Liquid Crystal Polymer (LCP)
Lead Spacing	2.0 mm
Lead Style	Surface Mount
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount, Right Angle
Number of Positions	20
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature	-55°C ~ 105°C
Pitch	2.00 mm
Row Spacing	0.079" (2.00mm)
SVHC Present	Not Present
Shrouding	Unshrouded
Style	Board to Board or Cable
Tape & Reel	Yes
Termination	Solder
Termination Style	Solder
