MMT-106-02-F-DH-A-K-TR 12-position surface mount right angle header from Samtec with 2mm pitch, rated 3A.
Mfr Part #:

MMT-106-02-F-DH-A-K-TR

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
12-position surface mount right angle header from Samtec with 2mm pitch, rated 3A.
✓ Total Stock: 2,000 pcs
$ Price Range: $1.71 - $2.87

MMT-106-02-F-DH-A-K-TR Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
2,000 pcs
On Request
2000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MMT-106-02-F-DH-A-K-TR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating (Amps)
Fastening Type
Features
Insulation Color
Insulation Height
Insulation Material
Lead Spacing
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Pitch
Row Spacing
Shrouding
Style
Tape & Reel
Termination
Termination Style
View Similar Products (0)

MMT-106-02-F-DH-A-K-TR Description

Short technical summary and product information.

The MMT-106-02-F-DH-A-K-TR is a 12-position unshrouded header manufactured by Samtec Inc. It features a 2.00mm pitch and two rows of square male pins, making it suitable for board-to-board or cable applications.



The header is surface mount with right angle orientation and uses phosphor bronze contacts with a tin finish. It is rated for 3A current and operates over a temperature range of -55°C to 125°C. The insulation is black liquid crystal polymer (LCP) with a UL94 V-0 flammability rating.



Design features include a board guide and pick-and-place capability, facilitating automated assembly. The contact length is 4.45mm and the insulation height is 4.00mm. With a push-pull fastening type, it provides reliable connection in compact spaces.

MMT-106-02-F-DH-A-K-TR Quick Information

Product Type: Header, Male Pins
Canonical Name: Samtec MMT-106-02-F-DH-A-K-TR Header, Male Pins
Subcategory: Male Pins

MMT-106-02-F-DH-A-K-TR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

MMT-106-02-F-DH-A-K-TR Estimated Pricing

Qty Low High
1+ $2.87 $2.87
50+ $2.66 $2.66
100+ $2.28 $2.28
375+ $2.23 $2.23
750+ $2.08 $2.08
1,875+ $1.89 $1.89
4,875+ $1.71 $1.71

Estimated market price range - modelled values for guidance only, not live distributor offers.

MMT-106-02-F-DH-A-K-TR Features

  • 12 positions in 2 rows at 2mm pitch.
  • Surface mount right angle termination style.
  • Rated 3A with 125°C maximum operating temperature.
  • Board guide and pick-and-place compatible.
  • Unshrouded header for board-to-board use.

MMT-106-02-F-DH-A-K-TR Applications

  • Suitable for compact electronic device interconnects.
  • Used in automated assembly with pick-and-place.
  • Ideal for board-to-board stacking applications.
  • Can be used in cable-to-board connections.

MMT-106-02-F-DH-A-K-TR FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the MMT-106-02-F-DH-A-K-TR have?

12 positions

What is the pitch of this header?

2.00mm

What is the current rating?

3A

What is the mounting type?

Surface mount, right angle

What is the contact material?

Phosphor bronze

What is the operating temperature range?

-55°C to 125°C

What is the insulation material?

Liquid crystal polymer (LCP)
