Mfr Part #:

MMT-105-01-T-DH-P-TR

2.00mm pitch 10-position header from Samtec with surface mount right angle mounting, tin-plated phosphor bronze contacts, and LCP insulation.

✓ Total Stock: 2,579 pcs

$ Price Range: $1.16 - $1.80

MMT-105-01-T-DH-P-TR Available from 2 distributors

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Components Technology Group, Inc. ✓ Non-Authorised Inventory information	2,356 pcs On Request	2356 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
MW.FEP S.p.A. ✓ Non-Authorised Inventory information	223 pcs On Request	223 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

MMT-105-01-T-DH-P-TR Description

Short technical summary and product information.

The Samtec MMT-105-01-T-DH-P-TR is a 10-position male pin header designed for board-to-board or cable interconnections. It features a 2.00mm pitch with 2 rows and is unshrouded, allowing flexible mating in space-constrained designs.

This header employs surface mount, right angle termination with solder leads. The contacts are made of phosphor bronze with a tin finish, offering reliable conductivity. The insulator is black Liquid Crystal Polymer (LCP) rated UL94 V-0 for flammability resistance.

Electrically, the connector is rated for 3A current and operates over a temperature range of -55°C to 105°C. It includes a pick and place feature for automated assembly. The insulation height is 4.00mm and contact length is 3.20mm.

Compliance data for RoHS, REACH, and MSL is unverified; verification is recommended before use. No datasheet is currently available from the manufacturer.

MMT-105-01-T-DH-P-TR Quick Information

Product Type: Header

Series: MMT

Canonical Name: Samtec MMT-105-01-T-DH-P-TR 10 Position 2.00mm Pitch Header, Surface Mount Right Angle

Subcategory: Unshrouded Header

MMT-105-01-T-DH-P-TR Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

MMT-105-01-T-DH-P-TR Estimated Pricing

Qty	Low	High
1+	$1.80	$1.80
50+	$1.57	$1.57
100+	$1.37	$1.37
400+	$1.27	$1.27
800+	$1.24	$1.24
2,000+	$1.21	$1.21
4,800+	$1.18	$1.18
10,000+	$1.16	$1.16

Estimated market price range - modelled values for guidance only, not live distributor offers.

MMT-105-01-T-DH-P-TR Features

2.00mm pitch for compact designs.
Surface mount right angle orientation.
Tin-plated phosphor bronze contacts.
Pick and place compatible.
UL94 V-0 rated LCP insulator.

MMT-105-01-T-DH-P-TR Applications

Suitable for board-to-board connections.
Used in cable-to-board applications.
Ideal for space-constrained PCB layouts.

MMT-105-01-T-DH-P-TR FAQs

7 frequently asked questions generated from this part’s specifications.

How many positions does the MMT-105-01-T-DH-P-TR have?

10 positions in 2 rows.

What is the pin pitch?

2.00mm (0.079").

What is the current rating?

3A.

What is the mounting type?

Surface Mount, Right Angle.

What is the operating temperature range?

-55°C to +105°C.

What is the contact material?

Phosphor Bronze with tin finish.

What is the flammability rating of the insulator?

UL94 V-0.

Category	Headers, Male Pins
Manufacturer Name	Samtec Inc.
Connector Type	Header
Contact Finish	Tin
Contact Length	3.20mm (0.126")
Contact Material	Phosphor Bronze
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	3A
Fastening Type	Push-Pull
Features	Pick and Place
Insulation Color	Black
Insulation Height	4.00mm (0.157")
Insulation Material	Liquid Crystal Polymer (LCP)
Lead Spacing	2.0 mm
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount, Right Angle
Number of Positions	10
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature	-55°C ~ 105°C
Pitch	2.00mm (0.079")
Row Spacing	0.079" (2.00mm)
SVHC Present	Not Present
Shrouding	Unshrouded
Style	Board to Board or Cable
Tape & Reel	Yes
Termination	Solder
