| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
288 pcs
|
288 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Forward Voltage | |
| Halogen Free | |
| Impedance (Max) (Zzt) | |
| Mounting Type | |
| Operating Temperature | |
| Power | |
| Supplier Device Package | |
| Tolerance | |
| Voltage |
The Micro Commercial MMSZ5243B-TP is a Zener diode designed for voltage regulation applications. It features a nominal Zener voltage of 13V with a tolerance of ±5%. The diode has a maximum power dissipation of 500 mW and a low reverse leakage current of 500 nA at 9.9V.
This component is housed in a compact SOD-123 surface-mount package, making it suitable for space-constrained designs. The operating temperature range is -55°C to +150°C, ensuring reliable performance across various environmental conditions. Its forward voltage is 900 mV at 10 mA.
The MMSZ5243B-TP series offers a wide range of Zener voltages from 2.4V to 75V, with this specific part operating at 13V. The planar die construction contributes to its robust performance. It is also noted as Halogen Free and Lead Free, aligning with environmental compliance standards.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal Zener voltage is 13V at a test current of 20 mA.
The maximum power dissipation is 500 mW.
The Zener voltage tolerance is ±5%.
This diode is supplied in a SOD-123 surface mount package.
The operating temperature range is -55°C to +150°C.
