| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,568 pcs
|
2568 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Type | |
| Current Rating (Amps) | |
| Data Rate | |
| Fastening Type | |
| Halogen Free | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead-Free Solderable | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Packaging Type | |
| Pitch | |
| Row Spacing | |
| SMT Lead Coplanarity | |
| Standard Package Quantity | |
| Style | |
| Tape & Reel | |
| Termination |
The Samtec MMS-125-01-L-DH is a member of the MMS series of classic socket strips. It is a 50-position, double-row (2 rows) receptacle with a 2.00mm pitch and 2.00mm row spacing. The connector is right-angle, through-hole mounted with solder termination. Contacts are phosphor bronze with 10 µ" gold plating (L plating) on the contact area and matte tin on the tails. The insulator is black LCP. The push-pull fastening type allows for board-to-board or cable mating. Electrical specifications include a current rating of 3.9A per contact and a data rate capability of 8 Gbps. The operating temperature range is -55°C to +125°C. The connector is lead-free solderable and has an MSL rating of 1 (unlimited). Packaging is in tubes of 11 pieces. This socket strip is suitable for applications requiring high density and reliable connections, such as industrial, automotive, and communications equipment.
| Qty | Low | High |
|---|---|---|
| 1+ | $9.75 | $9.75 |
| 11+ | $8.85 | $8.85 |
| 22+ | $8.63 | $8.63 |
| 55+ | $7.92 | $7.92 |
| 110+ | $7.63 | $7.63 |
| 253+ | $7.40 | $7.40 |
| 506+ | $6.70 | $6.70 |
| 1,001+ | $6.53 | $6.53 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The connector has 50 positions loaded in a 2-row configuration.
The pitch is 2.00mm (0.079").
The current rating is 3.9A per contact.
The mounting type is through hole, right angle.
The connector supports data rates up to 8 Gbps.
The operating temperature range is -55°C to +125°C.
The contact finish is 10 µ" gold on the contact area and matte tin on the tail.
