MMBT 3904 LT1 The Infineon MMBT 3904 LT1 is an NPN general purpose small signal transistor. It features a 40V collector-emitter voltage and 200mA collector current.
Mfr Part #:

MMBT 3904 LT1

Available from 2 distributors
Mfr Name: Infineon
Infineon
The Infineon MMBT 3904 LT1 is an NPN general purpose small signal transistor. It features a 40V collector-emitter voltage and 200mA collector current.
✓ Total Stock: 310 pcs
$ Price Range: $0.99

MMBT 3904 LT1 Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
290 pcs
On Request
290 pcs On Request 1 On Request On Request On Request On Request On Request
Speed Components Ltd ✓
Non-Authorised Inventory information
20 pcs
On Request
20 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MMBT 3904 LT1 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Delay Time
Mounting Type
Tape & Reel
Termination Style
Transistor Type
View Similar Products (0)

MMBT 3904 LT1 Description

Short technical summary and product information.

The Infineon MMBT 3904 LT1 is a versatile NPN bipolar junction transistor designed for general purpose amplification and switching applications. It offers a breakdown voltage of 40V and a continuous collector current capability of 200mA.



Key electrical characteristics include a minimum transition frequency of 300MHz, ensuring suitability for various signal processing tasks. The transistor is housed in a compact SOT-23 surface-mount package, making it ideal for space-constrained designs.



This component is well-suited for a wide range of electronic circuits requiring reliable amplification or switching. Its robust specifications and common package type make it a staple in many industrial and consumer electronics applications.

MMBT 3904 LT1 Quick Information

Product Type: NPN Transistor
Series: -
Canonical Name: Infineon MMBT 3904 LT1 NPN General Purpose Small Signal Transistor
Subcategory: Single

MMBT 3904 LT1 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

MMBT 3904 LT1 Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

MMBT 3904 LT1 Features

  • NPN general purpose small signal transistor.
  • 40V collector-emitter breakdown voltage.
  • 200mA maximum collector current.
  • 300MHz minimum transition frequency.
  • SOT-23 surface-mount package.

MMBT 3904 LT1 Applications

  • Suitable for general amplification circuits.
  • Used in signal switching applications.
  • Ideal for space-constrained designs.
  • Common in consumer electronics.

MMBT 3904 LT1 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the collector-emitter voltage rating?

The maximum VCEO is 40V.

What is the maximum collector current?

The maximum IC is 200mA.

What is the transition frequency?

The minimum fT is 300MHz.

What is the package type?

SOT-23 (TO-236) surface mount.

What is the DC current gain?

Minimum hFE is 100 at 10mA.

What is the power dissipation?

Maximum power dissipation is 225mW at ambient.

What is the collector-emitter saturation voltage?

300mV at IB=5mA, IC=50mA.
