| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
39 pcs
|
39 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Accuracy | |
| Applications | |
| Failure Rate | |
| Features | |
| Maximum Pressure | |
| Mounting Type | |
| Operating Pressure | |
| Operating Temperature | |
| Output | |
| Output Type | |
| Port Size | |
| Port Style | |
| Pressure Type | |
| Supplier Device Package | |
| Termination Style | |
| Voltage | |
| Voltage Supply |
The Amphenol MLV-005D-E1BS-N is a differential pressure sensor from the MLV series, designed for board mount applications. It measures pressure in the range of ±5 PSI (±34.47kPa) with an accuracy of ±0.5%. The sensor features a Wheatstone bridge output, providing a voltage output from 0 mV to 25 mV with a 5V supply.
This sensor operates within a temperature range of -25°C to 85°C and is temperature compensated. It has a barbed port style with a port size suitable for a 0.09" (2.24mm) tube. The package is a 4-SIP with dual ports on the same side, and it is designed for through-hole mounting.
Key specifications include a maximum pressure rating of ±10 PSI and a supply voltage of 12V, in addition to the primary 5V operating voltage. The part is RoHS3 compliant and has a Moisture Sensitivity Level (MSL) of 1 Unlimited.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.50 | $1.50 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating pressure range is ±5 PSI (±34.47kPa).
The accuracy is ±0.5%.
The output voltage is 0 mV to 25 mV with a 5V supply.
The operating supply voltage is 5V.
The operating temperature range is -25°C to 85°C.
It uses a 4-SIP package with dual ports on the same side.
It is designed for through-hole mounting.
