| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
25 pcs
|
25 pcs | On Request | 1 | On Request | On Request | 725 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Accuracy | |
| Applications | |
| Features | |
| Ingress Protection Rating | |
| Maximum Pressure | |
| Operating Pressure | |
| Operating Temperature | |
| Output | |
| Output Type | |
| Port Size | |
| Port Style | |
| Pressure Range | |
| Pressure Type | |
| Response Time | |
| Termination Style | |
| Total Error Band (TEB) | |
| Voltage |
The Honeywell MLH Series MLH03KPSB01B is a robust heavy-duty pressure transducer engineered for demanding industrial environments. It combines Application Specific Integrated Circuit (ASIC) technology with a media-isolated, metal diaphragm design for reliable performance.
This digitally compensated transducer offers a pressure range of up to 3000 PSI, with an accuracy of ±0.25% full scale. It operates within a wide temperature range of -40°C to 125°C and provides a 4 mA to 20 mA analog current output. The unit is fully temperature compensated, calibrated, and amplified, ensuring accurate measurements.
Featuring a 1/4" NPT male port and Packard Metripak 150 termination, the MLH03KPSB01B is suitable for industrial automation applications. Its construction is rated IP65 or better for protection against harsh environments. The transducer is designed with all-metal wetted parts and no internal elastomeric seals to eliminate compatibility issues.
Potential applications include compressors, cylinder tank pressure monitoring, HVAC systems, hydraulics, oil and gas equipment, refrigeration units, and water distribution systems.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.50 | $1.50 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pressure range is 6 bar to 550 bar, or 50 psi to 8,000 psi.
The accuracy is ±0.25% of full scale (BFSL).
The operating temperature range is -40°C to 125°C.
It provides a 4 mA to 20 mA analog current output.
The sensor requires a voltage input between 9.5V and 30V.
The ingress protection rating is IP65 or better.
