| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Medical Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| SVHC Present | |
| Stability | |
| Temperature Coefficient | |
| Type | |
| Voltage |
The SL Power Electronics ML15-0.4-A is a linear AC/DC power supply designed for various applications, including medical equipment. It provides a single output of 15V at 400mA, with a total power rating of 6W.
This converter accepts a universal AC input range of 100 to 240 VAC. Key electrical specifications include a line regulation of ±0.05%, load regulation of ±0.05%, and an output ripple of 3 mV peak to peak maximum. It offers features such as adjustable output, remote sensing, and automatic current limit/foldback for short circuit protection.
The unit is designed for chassis mounting and operates within a temperature range of 0°C to 70°C with derating. Its dimensions are 180.0mm x 82.6mm x 43.2mm. The power supply meets various safety and compliance standards, including CE, cURus, and TUV approvals, and is marked to LVD.
The ML15-0.4-A provides a 15V DC output voltage and a 400mA output current.
The ML15-0.4-A has a total power output of 6W.
The ML15-0.4-A supports a universal AC input range of 100 to 240 VAC.
The dimensions of the ML15-0.4-A are 180.0mm in length, 82.6mm in width, and 43.2mm in height.
The operating temperature range for the ML15-0.4-A is 0°C to 70°C with derating.
Yes, the ML15-0.4-A features automatic current limit/foldback for short circuit protection.
The ML15-0.4-A holds CE, cURus, and TUV approval agency certifications.
