| Category | |
| Manufacturer Name | |
| Efficiency | |
| Lead Style | |
| Mounting Type | |
| Output Current | |
| Output Voltage | |
| Package / Case | |
| Power |
The MINMAX MJW25-12S05 is a high-performance DC-DC converter module from the MJW25 series, delivering 25W of power in an ultra-compact 1"x1"x0.4" shielded metal package. It operates with a wide 2:1 input voltage range, specifically 9-18 VDC for the 12V input models, and provides a tightly regulated 5VDC output with an output current of 5000 mA.
This converter boasts excellent efficiency up to 90% and features 1500 VDC I/O isolation. The operating ambient temperature range is -40°C to +80°C, allowing for use in demanding environments. It includes overload, overvoltage, and short circuit protection, along with remote On/Off control and output voltage trim capabilities.
Designed for space-critical applications, the MJW25-12S05 is suitable for battery-operated equipment, instrumentation, data communication, and industrial systems. Its shielded metal case with an insulated baseplate ensures reliable operation and safety. The module is UL/cUL/IEC/EN 62368-1(60950-1) safety approved and CE marked.
The input voltage range is 9-75VDC, with specific sub-ranges of 9-18VDC, 18-36VDC, and 36-75VDC.
The available output voltages are 3.3V, 5V, 12V, and 15V DC.
The maximum output current varies by output voltage: 6000mA for 3.3V, 5000mA for 5V, 2090mA for 12V, 1670mA for 15V, and dual outputs provide ±1040mA or ±840mA.
The input-to-output isolation voltage is 1500VDC minimum.
The operating ambient temperature range is -40°C to +80°C.
The typical efficiency is 87% to 90%, depending on the model.
It is housed in a 1"x1" through-hole metal package with six-sided shielding and an insulated baseplate.
