| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
10 pcs
|
10 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Input Voltage | |
| Mounting Type | |
| Package / Case | |
| SVHC Present |
The MINMAX MJW15-12D12 is a cost-optimized, 15W isolated DC-DC converter housed in an encapsulated 1"x1" industrial standard package. It provides a wide 2:1 input voltage range and fully regulated output voltage.
Key electrical specifications include 1500VDC I/O isolation and an operating ambient temperature range of -40°C to +90°C. The converter features under-voltage, overload/voltage, and short circuit protection, along with remote ON/OFF control and trimmable output voltage.
Designed for critical space applications, this DC-DC converter offers a shielded metal case with an insulated baseplate and meets EN 55032 Class A conducted EMI standards. It is suitable for battery-powered equipment, instrumentation, and distributed power architectures in communication and industrial electronics.
Safety approvals include UL/cUL/IEC/EN 62368-1 and UL/cUL 60950-1, along with CE marking.
The input voltage range is 9-18 VDC.
The output voltage is ±12 VDC.
The maximum output current at maximum load is ±625 mA for each output.
The I/O isolation voltage is 1500 VDC.
The operating ambient temperature range is -40°C to +90°C.
It includes under-voltage, overload/voltage, and short circuit protection.
The package type is 1" x 1".
