The MINMAX MJW10-12S12 is a cost-optimized 10W isolated DC-DC converter housed in an industrial standard 1"x1" package. It features a wide 2:1 input voltage range and fully regulated output voltage with tight regulation.
Key electrical specifications include 1500VDC I/O isolation, an operating ambient temperature range of -40℃ to +80℃, and conducted EMI compliance with EN 55032 Class A. The converter also includes under-voltage, overload, and short circuit protection.
Designed for critical space applications, this DC-DC converter is suitable for battery-powered equipment, instrumentation, and distributed power architectures in communication and industrial electronics. Its shielded metal case with an insulated baseplate ensures reliable operation.
This series offers models for 12, 24, and 48VDC input with various output voltages. The MJW10-12S12 specifically operates within a 9-18VDC input range and provides a regulated output.
The input voltage range for the MJW10-12S12 is 9 to 18 VDC.
The MJW10-12S12 has a nominal output voltage of 3.3 VDC.
The maximum output current for the MJW10-12S12 is 2.5 A.
The I/O isolation voltage is a minimum of 1500 VDC.
The operating ambient temperature range is -40 to +80 ℃.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level is 1 Unlimited.
