Mfr Part #:

MJ10009

Mfr Name: ASI-Automation Systems Interconnect

The MJ10009 is an NPN Darlington power transistor from ASI-Automation Systems Interconnect. It offers a high breakdown voltage and current handling capability.

✓ Total Stock: 2 pcs

$ Price Range: $0.11

MJ10009 Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Bristol Electronics ✓ Non-Authorised Inventory information	2 pcs On Request	2 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

MJ10009 Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	ASI-Automation Systems Interconnect
Mounting Type	Through Hole
Power Dissipation	175 W
Transistor Type	Darlington

View Similar Products (0)

MJ10009 Description

Short technical summary and product information.

The MJ10009 is an NPN silicon power Darlington transistor manufactured by ASI-Automation Systems Interconnect. This component is designed for general-purpose power applications.

Key electrical characteristics include a maximum Collector-Emitter Voltage (V(BR)CEO) of 500V and a maximum Collector Current (IC) of 20A. It has a minimum DC Current Gain (hFE) of 30 and a nominal transition frequency (fT) of 8 MHz. The device can dissipate up to 175W of power.

The transistor is housed in a TO-204AE package, which is a flange mount type. This packaging is suitable for through-hole mounting.

This transistor is part of the SWITCHMODE series, indicating its suitability for switching applications.

MJ10009 Quick Information

Product Type: NPN Darlington Power Transistor

Series: SWITCHMODE

Canonical Name: MJ10009 NPN Darlington Power Transistor

Subcategory: Bipolar (BJT) - Single

MJ10009 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

MJ10009 Estimated Pricing

Qty	Low	High
1+	$0.11	$0.11

Estimated market price range - modelled values for guidance only, not live distributor offers.

MJ10009 Features

NPN Silicon Power Darlington Transistor
500V Collector-Emitter Voltage (V(BR)CEO)
20A Maximum Collector Current (IC)
175W Power Dissipation (PD)
TO-204AE Flange Mount Package

MJ10009 Applications

Suitable for power switching circuits
General purpose power applications
Industrial automation systems
Process automation control

MJ10009 FAQs

7 frequently asked questions generated from this part’s specifications.

What is the collector-emitter voltage rating of the MJ10009?

500V (maximum).

What is the maximum collector current?

20A.

What is the power dissipation rating?

175W.

What is the package type?

TO-204AE.

What is the transistor type?

NPN Darlington.

What is the DC current gain (hFE)?

Minimum 30.

What is the transition frequency?

8 MHz typical.
