| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
10 pcs
|
10 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Efficiency | |
| Mounting Type | |
| Output Current | |
| Output Voltage | |
| Package / Case | |
| SVHC Present |
The MINMAX MIW10-48S05 is a cost-optimized, 10W isolated DC-DC converter housed in an industrial standard DIP-24 package. It supports a wide 2:1 input voltage range, making it versatile for various power applications. The converter provides a fully regulated output voltage with high efficiency up to 89% and features 1500 VDC of I/O isolation.
Designed for demanding environments, the MIW10-48S05 operates reliably within an ambient temperature range of -40℃ to +85℃. It includes essential protection features such as under-voltage, overload, and short circuit protection, along with remote On/Off control. The unit also boasts low no-load power consumption and requires no minimum load.
These DC-DC converters are suitable for critical space applications, reducing PCB layout demands. They are ideal for use in battery-powered equipment, instrumentation, and distributed power architectures within communication systems, industrial electronics, and energy facilities.
The MIW10-48S05 has a 48VDC input voltage range of 36 to 75 VDC.
The MIW10-48S05 provides a 5 VDC output voltage at a maximum current of 2000 mA.
The typical efficiency of the MIW10-48S05 at maximum load is 85%.
The MIW10-48S05 offers a minimum I/O isolation voltage of 1500 VDC.
The MIW10-48S05 can operate in an ambient temperature range from -40℃ to +85℃.
Yes, the MIW10-48S05 features continuous short circuit protection with automatic recovery.
