| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
20 pcs
|
20 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Efficiency | |
| Mounting Type | |
| Output Current | |
| Output Voltage | |
| Package / Case |
The MINMAX MIW06-24S15 is a high-performance DC-DC converter module from the MIW06 series, delivering 6W of output power. It features an industrial standard DIP-24 package with a wide 2:1 input voltage range, specifically 18-36 VDC for this model, and provides a fully regulated 15 VDC output at up to 400mA.
This converter offers excellent efficiency, allowing for operation in an ambient temperature range of -40℃ to +85℃. Key features include under-voltage protection, overload protection, and short circuit protection, with no minimum load requirement. The I/O isolation is rated at 1500 VDC.
Typical applications for the MIW06 series include battery-powered equipment, instrumentation, datacom, and industrial electronics where reliable power conversion is essential. The product meets EN 55022 Class A conducted EMI standards and holds UL/cUL/IEC/EN 62368-1 safety approvals.
The MIW06-24S15 has a nominal output voltage of 15 VDC.
The maximum output current for the MIW06-24S15 is 400 mA.
The input voltage range for the MIW06-24S15 is 18 to 36 VDC.
The typical efficiency of the MIW06-24S15 at maximum load is 84%.
The I/O isolation voltage for the MIW06-24S15 is a minimum of 1500 VDC.
The operating ambient temperature range for the MIW06-24S15 is -40℃ to +85℃.
The output voltage accuracy of the MIW06-24S15 is ±2.0% maximum.
